Large Format Scanning Drawings by ARDEM

Scanning Drawings

Scanning Drawings which are up to 42 inch wide and up to 600 DPI resolution. All large format scanning is done on state of the art wide format scanners. ARDEM provides high quality scanning of large format scanning for drawings in color, gray-scale and in Black and White.

Scanning which Drawings ?

ARDEM scans architectural drawings, engineering drawings, construction plans, facility plan layout drawings. These drawings could be Black and White, Blueprints, Blue-line drawings. We can scan drawings which were originally created on paper, Mylar, onion skin and even on linen. Drawings are typically scanned scanned to Tiff, PDF or JPEG formats.

Drawing Scanning Process

Drawings are picked up at your location, or, you can mail them to our processing location.

We will prepare the drawings for scanning- which based on the condition of drawing can be only flattening the drawing, or could be as elaborate as repairing any torn drawings, or placing a fragile drawing in a clear laminate sleeve before scanning.

Drawings very often require optimization of scanner settings to achieve the best quality of scan images. This is very often driven by the condition of drawing, whether it is a blue line, whether it is on paper or Mylar or onion skin paper.

After scanning  the meta data index is created which allows for ease of search and retrieval of the scan image of the drawing.

Scanning Drawings Everywhere

Large Format Scanning for Drawings for our clients in New York, New Jersey, Philadelphia, Washington D.C., Virginia, Maryland, Connecticut and Massachusetts.

Why Large Format Scanning Drawings by ARDEM?

ARDEM has scanned architectural drawings, engineering drawings and construction plans. Some drawings have been Black & White on paper, others on Mylar, still others came as blueprints and onion skin paper. Scanning of drawings is done with great care with individual settings for each drawing to assure the best digital scan of the drawing. Fragile drawings were first placed in clear laminate sleeve before scanning of the drawing.

Each drawing requires optimization for resolution, brightness, contrast , noise drop-out to insure that the digital image is  the best quality possible.
